Uflow 2 Inch 2/2 Way Steam Solenoid Valve - Pilot Operated Piston Type Solenoid Valve for Steam SS304 with Metallic Round LED Coil - Screwed Ends

Uflow 2 Inch 2/2 Way Steam Solenoid Valve - Pilot Operated Piston Type Solenoid Valve for Steam SS304 with Metallic Round LED Coil - Screwed Ends

Brand UFLOW

₹ 8240 (Incl. of all taxes)

₹ 6983 + ₹ 1257 GST

MRP ₹10299

Select Options:

230v AC

24v DC

110v AC

Offers and Coupons

Save instantly 2% with online payment.

via UPI, EMI, Credit/Debit Card, Net Banking, Wallets.

Get flat Rs. 100 OFF

Min cart value ₹10,000

INDUSO100

Click to Copy

Get GST invoice and save up to 18% on business purchases

VIEW

Brand Warranty

100% Genuine Products

Safe & Secure Payment

Nationwide Delivery

Multi-Brands

Weight	3.4 KG

PORT

Refer technical data sheet (Available in BSP threading)

END CONNECTION

Screwed

BODY MATERIAL

SS ASTM A351 Grade CF8

SEAL & O RING
MEDIA TEMP.

PTFE + Sp. VITON

-10° C to 180° C

CIRCUMSTANCE TEMP.

-10° C to 70° C

MEDIA

Steam, Hot Water, Hot Fluid, Hot Oil

MAIN FEATURES

Internal Parts are in superior corrosion resistance steel, (Equivalent to SS316L) Suitable for Food Industries, Pharmaceuticals, Chemical application & Highly corrosive environment

OPERATING VOLTAGE
POWER CONSUMPTION

24AC	110AC	230AC	12DC	24DC
7W	8W	8W/15W	10W	11W

COIL FEATURES

High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4X90 position or freely movable in between as require.

OTHER COIL TYPES

Metallic Round Coil with Lead Wire, Epoxy Moulded Coil with LED, IP-68 Weather Proof Coil, IP-67 Flame Proof Coil

OPTIONAL FEATURE

90% Power saver series also available, Manual Override, Water hammering reducer also available to avoid water hammer forces.

OTHER SPECIFICATION DATA

Available on Request

NOTE: Use of filter in the inlet port is recommended.

Model No.	Body Material	Pipe (Inch)	Orifice (mm)	Min. Operating Pressure Kg/cm²	Max. Operating Pressure Kg/cm²	Seal & Diaphram Material	Flow Factor Kv m³/hr
HCP89	CF8 (SS304)	2"	48	1.5	12	PTFE	28

* Note – Body Material : CF8M (SS316) on request

Size	2"BSP
Coil Type	Metallic Round Coil with LED DIN Connector
Valve Type	2/2 way Normally Closed Steam Solenoid Valve
Body Material	SS304 (ASTM A351 Grade CF8)
Pressure Range	1.5 to 12 kg/cm2 (bar)
Temperature (Media)	-10° C to 180° C
Seal	PTFE + Sp. VITON
Media	Suitable for Steam & Hot Fluids, Air, Water, Gas, Chemical
Other Specification / Data	Check the tabs given below for details
